Power Supply with Analog Meter, Continuous Type. This equipment is commonly used in school laboratories and other educational settings. Here are the key details:

1. Description:

   • The power supply provides continuously variable AC and DC outputs up to 1 Amp for both AC and DC.
   • It features a built-in analog meter that indicates both AC and DC voltages.
   • The voltage range is 0-12V for both AC and DC.
   • Additionally, there’s a step-type version available with a 2 Amp output for both AC and DC.

2. Applications:

   • School Laboratories: Ideal for educational purposes in developing countries across Asia, Africa, and South America.
   • Custom Panels: Suitable for stand-alone metering in custom panels, switchboards, and motor control centers.
   • Basic Metering: Offers accurate power, energy, and demand measurements.
   • Cost Allocation / Energy Monitoring: Useful for monitoring cost centers, identifying demand control opportunities, and analyzing energy consumption patterns.

3. Specifications:

   • Input Range: 100-120 VAC or 200-240 VAC (user switchable)
   • Output Voltage: Variable 0-12V DC
   • Output Amperage: 25 continuous, 28 surge
   • Polarity Ground: Negative
   • Internal Protection: Thermal, over current
   • Ripple Peak-to-Peak: <100mVpp
   • Operating Temperature: 0°C to 50°C
   • Dimensions: 154mm long, 127mm wide, 63mm tall

4. Integration and Communication:

   • The power supply provides open communications using Modbus RTU/TCP, PROFINET, and PROFIBUS-DP protocols.
   • Configuration can be done from the front display or using a PC with SENTRON powerconfig setup software.

5. Energy Consumption Analysis:

   • To reduce power costs, analyze the electrical system’s current consumption and power flows.
   • The power meter precisely delivers required power values for cost reduction.
